Available
CPU 400 MHz DSP
Memory 8 MB flash + 16 MB RAM
Fingerprint sensor 500 dpi optical sensor
Identification speed 2,000 matches in 1 second
Fingerprint capacity 5,000 fingerprints (10,000 templates)
Log capacity 50,000 events
RF card Mifare (13.56 MHz)
Authentication Finger and/or PIN and/or Card
Network interface TCP/IP, RS485, Wiegand 1 channel(input/output switchable)
TTL I/O 2 inputs for exit switch and door sensor
Internal relay Deadlock, EM lock door strike, automatic
door
Ingress protection rate IP 65 class
LCD 128 x 64 pixel, black & white
Keypad 3 x 4 keypad, 3 navigation keys
Sound and interface Multi-color LED and multi-tone buzzer
Operating voltage 12 Vdc
Size (W x H x D) 60 x 185 x 40 mm
